Introducing the GP Factor Ineos Grenadier Bull Bar Grill Guard. Our mission in designing this bull bar was to create a strikingly aesthetic yet robust and functional product for the Grenadier, and also fully made right here in the USA. The result is a uniquely crafted bull bar made from five separate pieces, rather than a single solid unit, allowing for enhanced versatility and ease of use. Here are some key benefits of our innovative design:

Easy Replacement: Damage to the outer sections can be easily fixed by replacing only those parts.
Versatile Options: Middle tube sections can be swapped out to accommodate various light mounting choices in the future.
Effortless Shipping: Individual pieces make shipping simpler and safer, reducing freight costs and eliminating complications at the time of delivery.
Enhanced Durability: Our multi-piece design is engineered for superior strength and longevity. Constructed from 3/16” (0.187) HRPO A36 Carbon Steel with 1.9” diameter tubing featuring 0.125” (1/8”) thick walls, this bull bar is built to withstand the demands of rugged use. The main pillars boast an I-Beam construction for added strength and an impressive look. With pillars and bar mounts all measuring 3/16” thick, when assembled, the combined thickness reaches 9/16”.

The bull bar mounts securely to the bumper using eight factory mounting holes on each side—four M10 in the front, two M6 at the top rear, and two M6 on the bottom—to ensure stability and support without any modifications required. All included hardware is crafted from A4 Marine Grade Stainless Steel with a Black Oxide Finish for superior resistance to corrosion.

Specifications:

Material: Sheet formed steel : HRPO PRIME ASTM A 1011 Grade 36 Type 2, Tubing: HRPO PRIME ASTM A513 MT1010 Type 1
Finish: bead blasted, Zinc Primer, and Textured Black Powder Coating
Weight: Approximately 55 lbs (Shipped weight of both boxes is 58 lbs)
Origin: Made in the USA
Compatibility: Factory Bumpers with or without factory winches, and factory bumpers with GP Factor winch kits on Grenadier and Quartermaster.

Elevate your Ineos Grenadier with our expertly engineered bull bar, blending functionality and style seamlessly!

*ALL SHIPPING IS FREE IN THE CONTINENTAL UNITED STATES. WE DO SHIP OVERSEAS WHICH WILL BE CALCULATED AT CHECKOUT.*

DISCLAIMER: This product is not intended to serve as a recovery point and should not be used as such. While it is a robust and well-crafted item, it is not designed to function as a brush guard for pushing, pulling, or making contact with vehicles, livestock, or any other objects. GP Factor does not provide a warranty for this product against improper use, collisions, or incorrect installation. Additionally, this product is not crash tested. GP Factor assumes no responsibility for any damage caused to or by this product resulting from a collision or crash.

CLICK HERE FOR INSTALLATION INSTRUCTIONS
